SIEMENS SIMATIC SIPLUS ET 200SP TM COUNT 1X24V T1 RAIL Bangladesh. Mlfb-6AG2138-6AA01-1BA0 price

The Siemens 6AG2138-6AA01-1BA0 is a SIPLUS extreme RAIL TM Count 1x24V T1 RAIL technology module for counting and position-detection applications. It is based on the standard 6ES7138-6AA01-0BA0 and provides one 24 V counter channel, 3 digital inputs and 2 digital outputs. Published product data specifies a maximum incremental encoder input frequency of 200 kHz and a maximum counting frequency of 800 kHz with quadruple evaluation. The module supports firmware updates, I&M data and isochronous operation and is designed for harsh railway and industrial environments. SIPLUS extreme RAIL specifications include conformal coating and extended environmental capability.

2. Technical Specification

Specification	Details
Manufacturer	Siemens
Product Code	6AG2138-6AA01-1BA0
Product Family	SIPLUS extreme RAIL TM Count 1x24V
Product Type	T1 RAIL counter technology module
Based On	6ES7138-6AA01-0BA0
Rated Voltage	24 V DC
Counter Channels	1
Digital Inputs	3
Digital Outputs	2
Incremental Encoder Frequency	200 kHz max.
Counting Frequency	800 kHz max. with quadruple evaluation
Encoder Supply Current	300 mA max.
Base Unit	Type A0
Operating Temperature	-40 to +60 °C
Firmware Update	Yes
I&M Data	I&M0 to I&M3
Isolation Test	750 V DC type test

3. Key Features

• SIPLUS extreme RAIL technology module.
• One-channel 24 V counting.
• 3 digital inputs and 2 digital outputs.
• Up to 200 kHz incremental encoder input frequency.
• Up to 800 kHz counting frequency with quadruple evaluation.
• Conformal-coated design.
• Extended environmental capability.
• Firmware update support.
• I&M data support.
• Isochronous operation.
• Diagnostic functions.
• Type A0 Base Unit compatibility.

4. Typical Application

• Railway automation.
• Rolling-stock-related automation systems.
• Harsh industrial environments.
• Encoder counting.
• Position detection.
• Machine and equipment monitoring.
• Distributed ET 200SP technology applications.

5. Product Highlights

The 6AG2138-6AA01-1BA0 is designed for applications requiring the TM Count technology function with SIPLUS extreme RAIL characteristics. Its 24 V encoder interface, high-speed counting capability and environmental design make it appropriate for demanding transportation and industrial automation environments.

6. Important Ordering & Installation Information

The exact article is 6AG2138-6AA01-1BA0. It is based on 6ES7138-6AA01-0BA0 and requires the compatible ET 200SP Base Unit arrangement specified by Siemens. The module's environmental and railway suitability should be assessed against the complete system installation and applicable railway requirements.

Always follow the manufacturer's official installation, wiring, commissioning and safety instructions.

7. Why Choose Siemens 6AG2138-6AA01-1BA0 SIPLUS extreme RAIL TM Count?

The 6AG2138-6AA01-1BA0 provides a dedicated high-speed counter function with the SIPLUS extreme RAIL environmental design. Its 24 V encoder support, 800 kHz maximum counting capability and digital I/O make it suitable for demanding counting and position-detection applications.

8. Product Summary

The Siemens 6AG2138-6AA01-1BA0 is a SIPLUS extreme RAIL TM Count 1x24V T1 RAIL technology module based on 6ES7138-6AA01-0BA0. It provides one counter channel, 3 digital inputs and 2 digital outputs and supports incremental encoder input frequencies up to 200 kHz and counting frequencies up to 800 kHz with quadruple evaluation. Firmware updates, I&M data and isochronous operation are supported. The module is intended for demanding industrial and railway automation environments.

Product Code: 6AG2138-6AA01-1BA0
Manufacturer: Siemens
Product Family: SIPLUS extreme RAIL TM Count 1x24V
Product Type: T1 RAIL counter technology module
